Flexible electric rubberized cable standard fg16or16 3x2,5mmq icel

Butyl rubberized electric cable fg7 3 x 2,5 mmq
conductor: red copper, flexible formation, class 5
insulation: rubber, g7 quality
filler: thermoplastic, penetrating between the cores (only in multipolar cables)
sheath: pvc, rz quality
color: grey

functional characteristics

rated voltage uo / u: 0.6 / 1 kv
maximum working temperature: 90 ° c
maximum short circuit temperature: 250 ° c
particular characteristics
good resistance to industrial oils and greases. good behavior at low temperatures.
installation conditions
minimum installation temperature: 0 ° c
minimum recommended bending radius: 4 times the diameter of the cable
maximum recommended tensile stress: 5 kg per mm² of copper section
use and type of installation
suitable for the transport of energy in industry, on construction sites, in residential buildings.
for fixed installation indoors and outdoors. installation on walls and metal structures, on walkways, pipes, channels and similar systems.
underground installation allowed, even if not protected. (cei 20-67)
