Npi fror electric multipole cable
- 450 / 750v section 5x1.5mmq
for non-propagating fire and non-propulsion
reduced emission of halogen (corrosive gases) insulated under pvc sheath
pvc with red copper flexible conductor. imq-cpt-007 cei 20-20 / 1 cei
20-20 / 2
cei 20-22 ii cei en 50267-2-1
cei en 50265-2-1 cei 20-52
conductor: red copper flexible training class 5 npi fror - 450/750 v
insulation: pvc ti2 quality
sheath: pvc tm2 quality
color: grey.
npi® = not propagating the fire
functional characteristics
rated voltage uo / u: 450/750 v
maximum operating temperature: 70 ° c
maximum short circuit temperature: 160 ° c
particular characteristics
good resistance to mechanical stress and chemical agents.
good flexibility and low temperature behavior.
conditions of installation
minimum setting temperature: 0 ° c
minimum bending radius recommended: 10 times the cable diameter for laying
mobile 4 times for fixing.
maximum recommended tensile stress: 1.5 kg per mm² of copper section per
mobile laying 5 kg per mm² for fixed installation
use and type of laying
installation for mobile and fixed installation in places with fire hazard such as
fairs residential construction industry and crafts.
they can be installed inside in normal or humid environments and
temporarily outside.
- also sold by metro.
- 100mt on the mat
- gray color fror
- section 5x1.5 mmq
