Modular gray home automation switch with 1 controlled circuit 230V

The single channel home automation switch is designed to control different types of lamps, including incandescent, LED, CFL and FL lamps. Compatible with all commands of the DOMO myLife system, this switch can be managed and controlled via iOS and Android mobile devices thanks to the D myLife app. The status of the actuator is visible in the app and the output can be programmed to operate even after the supply voltage fails. The switch has four operating modes when activated by commands (on/off, bistable, monostable, timed) and two operating modes when controlled by the D myLife app (on/off, timed). The RF transmission is encrypted and the operating range is up to 250 meters in open areas. The switch has a 230V∞ voltage output and can manage non or slightly inductive loads such as resistance burners, incandescent lamps, CFLs, LEDs and FLs, with a maximum power of 750W for incandescent lamps, 60W for lamps LED, 250W for CFL lamps and 375W to 500W for FL lamps. The switch is powered at 230V∞ and represents an ideal solution for controlling different types of lamps in a home or office.


Characteristics
· compatible with all commands of the DOMO myLife system · management and control from iOS and Android mobile devices
(tablet and smartphone) with the D myLife app
· status of the actuator displayed in the D myLife app
· 1 output channel (230V∞ voltage output)
· state of the programmable output
after a drop in the supply voltage
· 4 operating modes
when activated by commands
(turn on/off, bistable, monostable, timed) · 2 operating modes when commanded
from the D myLife app (on/off, timed)
· encrypted RF transmission
· long operating range (up to 250 m in open areas) · 230V∞ power supply

Loads supported
· incandescent lamps (AC5b) max 750W
· max 60W LED lamps
· CFL lamps (AC5a) max 250W
· FL lamps (AC5a) min 375W max 500W
· non or slightly inductive loads,
resistance ovens (AC1) max 1250VA
